EX Series Engines

EX Series Engines

Power and performance made easy.

With more power levels and two Briggs & Stratton innovations, our EX Series push mower engines are both easier to start and easier to maintain. There’s no need to prime or choke; just pull the rope or turn the key to get started. Special engineering allows these engines to run their full life without ever needing an oil change. No hassle, no mess. Just easy.

  • No oil changes needed – just add oil as needed and go with Just Check & Add™.
  • Easy, one-step starting with ReadyStart®.
  • Made in the USA of US and global parts.

5.5 - 6.25

Gross Torque (ft-lbs)

140 - 150cc

Displacement

Gas

Engine Fuel

ReadyStart®

Starter

Features

Made in the USA

Made in the USA of US and global parts.

ReadyStart® Starting Technology

No prime, no choke; just pull for power.

Super Lo-Tone™ Engine Muffler

A quieter lawn mowing experience.

Tool-less Air Cleaner Cover

Easy access for filter changes.

Specs

Only 2 products can be compared at once. Please remove one of your selections to compare this product.

Only 3 products can be compared at once. Please remove one of your selections to compare this product.

At least one product must be displayed. Please select another option to remove this product

Model Number
09P7
Torque (ft-lbs, gross)*
5.5
Engine Displacement (cc)
140
Number of Cylinders
Single
Engine Configuration
Vertical Shaft
OHV Engine
true
Length (in)
13.8
Width (in)
12.2
Height (in)
9.6
Weight (lbs)
17
Bore (in)
2.50
Stroke (in)
1.75
Engine Fuel
Gasoline
Fuel Tank Capacity (gal)
0.2
Oil Capacity (oz)
15
Lubrication System
Dura-Lube Splash Lubrication
Oil Filter
N/A
Starter
ReadyStart® Starting System
Air Filter
Dual-Sealing Paper
Muffler
Super Lo-Tone™
Fuel Shutoff Valve
N/A
Certified Power Rating

*All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.

Model Number
093J
Torque (ft-lbs, gross)*
6.25
Engine Displacement (cc)
150
Number of Cylinders
Single
Engine Configuration
Vertical Shaft
OHV Engine
true
Length (in)
13.8
Width (in)
12.2
Height (in)
9.6
Weight (lbs)
17
Bore (in)
2.58
Stroke (in)
1.75
Engine Fuel
Gasoline
Fuel Tank Capacity (gal)
0.2
Oil Capacity (oz)
15
Lubrication System
Dura-Lube Splash Lubrication
Oil Filter
N/A
Starter
ReadyStart® Starting System
Air Filter
Dual-Sealing Paper
Muffler
Super Lo-Tone™
Fuel Shutoff Valve
N/A

*All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.
**All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.
