XR 5.0

Click and drag image to rotate.

XR 5.0

High Performance and Extended Durability

Dura-Bore™ Cast Iron Sleeve
Cartridge Air Cleaner with Standard Pre-Cleaner

Click and drag image to rotate.

5.0

Horsepower (HP)

163cc

Displacement

Gasoline

Engine Fuel

Manual Choke

Starter

Features

Qualified 3x the Life

Qualified 3x the life of the CR engine. *When compared to the expected life standards of the Briggs & Stratton CR Series engine.

XR Professional Warranty

2-Year Commercial Warranty, 2-Year Consumer Warranty

Forged Crankshaft and Dura-Bore™ Cast Iron Sleeve

Combining a Forged Crankshaft that gives you a longer engine life and a Dura-Bore™ Cast Iron Sleeve that helps withstand the wear and abuse delivers durability.

Specs

Model Number

1062

Horsepower (HP, gross)*

5.0

Torque (ft-lbs, gross)*

7.5

Engine Displacement (cc)

163

Number of Cylinders

Single

Engine Configuration

Horizontal Shaft

OHV Engine

true

Length (in)

11.3

Width (in)

14.6

Height (in)

14.0

Weight (lbs)

33.6

Bore (in)

2.68

Stroke (in)

1.77

Engine Fuel

Gasoline

Fuel Tank Capacity (gal)

0.8

Lubrication System

Dura-Lube Splash Lubrication

Oil Capacity (oz)

Oil Filter

N/A

Starter

Manual Choke

Air Filter

Flat Panel or Dual Element Cartridge

Muffler

Lo-Tone™

Certified Power Rating

Download Power Curve

^{*Power levels are stated gross horsepower per SAE J1940 as rated by Briggs & Stratton.}
